Learn about Dacia SuperNova 2001-2003 fuse box and relay’s locations, functions, and maintenance tips for optimal vehicle electrical system.

The Dacia SuperNova (2001-2003) is a compact car that features a practical and straightforward design, available primarily as a five-door hatchback. This body style emphasizes versatility and ease of access, making it a popular choice for urban drivers and families alike. The SuperNova is characterized by its simple lines, functional interior, and ample cargo space, which cater to the needs of everyday users.

Integral to the vehicle’s functionality is its electrical system, which includes the fuse box and relays. The fuse box is typically located under the dashboard and houses fuses that protect electrical circuits for components such as lights, wipers, and the audio system. The relays, usually found adjacent to the fuse box, control larger electrical loads, including the fuel pump and cooling fans. Maintaining these components is essential for ensuring the reliability of the Dacia SuperNova’s electrical systems. Regularly checking the fuse box and relays helps prevent potential failures, ensuring that the vehicle continues to operate smoothly and efficiently for its users.

MUST READ: DYI – How to Check Car Fuses?

(2001-2003) Dacia SuperNova fuse box and relay with Diagram

WARNING

  • Never replace a fuse with one that has a higher amperage rating.
  • A fuse with a too-high amperage could damage the electrical part and cause a fire.
  • On no account should fuses be repaired (e.g. patched up with tin foil or wire) as this may cause serious damage elsewhere in the electrical circuit or cause a fire.
  • If a fuse blows repeatedly, do not keep replacing it. Instead, have the cause for the repeated short circuit or overload tracked and fixed.
  • Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.

Dacia SuperNova 2001-2003 fuse assignment

Year of production: from 2000, 2001, 2002, 2003

Fuses

Dacia SuperNova – fuse box diagram
Dacia SuperNova – fuse box diagram
AComponent
F0115Clock, radio, STOP contact, climate blower relay control
F025Reverse driving contact
F0315UCE decoder, speed transducer, instrument panel supply, diagnostic socket, AC starting button, UCE anti intrusion
F047,5Turning and hazard lights
F055Front/rear parking lights, lighting: switches, instrument panel, climate control, documents compartment, cigarette lighter, ashtray, radio
F0615Cigarette lighter, instrument panel (anti-starting indicator), front right ceiling lamp, UCE anti-intrusion, anti-intrusion indicator, diagnostic socket
F0715UCE decoder, FLASH relay, anti starting bushing
F0820Rear window defrosting
F0915Climate blower
F105Left fog lamp

On the fuse box, 6 fuses modules are attached, protecting the following consumers:

Dacia SuperNova - fuse box diagram
Dacia SuperNova – fuse box diagram
AComponent
F1110Left high beam
F1210Right high beam, high beam indicator
F1310Left low beam
F1410Right low beam, low beam indicator
F1515Windscreen wiper-washing switch, windscreen wiper timer
F1610Radio, windscreen wiper motor.

Conclusion

For owners and enthusiasts of classic Dacia SuperNova 2001-2003, understanding the fuse box and relay systems is essential for vehicle maintenance. Regular inspection and maintenance of these components helped ensure the vehicle’s longevity and reliability, preserving its status as a symbol of Dacia’s craftsmanship and innovation in the automotive industry during that era.
