The 2024-2025 Buick Encore GX is a compact crossover SUV with a sleek, modern design that combines style and practicality. Available in various trims, it emphasizes premium materials and advanced technology within a compact body style. The Encore GX offers a spacious interior with flexible seating, making it ideal for urban driving and family use. Key features include advanced driver-assistance systems, premium infotainment, and efficient powertrains, enhancing both comfort and safety.
To support these features, the Encore GX’s electrical system relies on well-organized fuse boxes and relays. The main fuse box is located under the hood, near the engine bay, while an additional fuse box can often be found inside the cabin, near the front passenger or driver’s side. The relays, which manage higher-power components like the ignition and fuel pump, are positioned near these fuse boxes. Regular inspection of these parts ensures the reliability of crucial vehicle functions.
MUST READ: DYI – How to Check Car Fuses?
(2024-2025) Buick Encore GX fuse box and relay with Diagram
WARNING
- Never replace a fuse with one that has a higher amperage rating.
- A fuse with a too-high amperage could damage the electrical part and cause a fire.
- On no account should fuses be repaired (e.g. patched up with tin foil or wire) as this may cause serious damage elsewhere in the electrical circuit or cause a fire.
- If a fuse blows repeatedly, do not keep replacing it. Instead, have the cause for the repeated short circuit or overload tracked and fixed.
- Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.
Buick Encore GX 2024-2025 fuse assignment
Buick Encore GX Year of production: 2024, 2025
Location of Fuse Boxes
Engine Compartment Fuse Block:
To remove the fuse block cover, squeeze the clip and lift it up.
Instrument Panel Fuse Block:
The instrument panel fuse block is on the underside of the driver side instrument panel. To access the fuses, open the fuse cover by pulling out. To reinstall the cover, insert the top tab first, then push the cover back into its original location.
Rear Compartment Fuse Block:
The rear compartment fuse block is behind a cover on the driver side of the rear compartment. To access the fuses, remove the cover.
Fuse Box Diagrams
2024-2025
Engine Compartment Fuse Block
List of fuses in the Engine Compartment Fuse Block (2024-2025)
№ | Usage |
---|---|
Micro Fuses | |
F02 | CLSTR |
F03 | N/A |
F06 | OSRVM DEFOG |
F07 | L/GATE RELSE |
F08 | N/A |
F09 | VENT SEAT |
F10 | N/A |
F11 | N/A |
F12 | N/A |
F14 | ISRVM REAR VIEW CAMERA |
F15 | N/A |
F16 | HDLP LVL |
F17 | N/A |
F18 | FTZM |
F19 | N/A |
F20 | N/A |
F22 | TRLR ST/TRN LT – TRLR |
F24 | ESCL |
F25 | ECM TCM RUN/CRNK |
F26 | FRT/REAR WSW PUMP |
F27 | IGN COIL – GAS |
F28 | AERO SH |
F29 | AHL AFL MDL |
F31 | ECM PT2 |
F32 | ENG COMP2 |
F33 | RVC |
F34 | FRT FOG LP |
F35 | ENG COMP1 |
F36 | ECM PT1 |
F38 | TRLR PRK LAMP – TRLR |
F40 | N/A |
F41 | REAR WPR |
F42 | HORN |
F44 | REAR WPR PRK |
F45 | A/C CLTCH |
F46 | N/A |
F47 | ECM BATT – GAS |
F49 | HDLP HI LH |
F50 | N/A |
F51 | HDLP HI RH |
F52 | TRLR ST/TRN RT – TRLR |
F53 | AUX WATER PUMP |
F54 | PEPS |
F56 | CNSTR VENT SOL – GAS |
F57 | N/A |
F58 | TCM BATT |
SF01-SF06 | Spare Fuses |
ET Fuses | |
F48 | N/A |
J-Case Fuses | |
F01 | N/A |
F05 | N/A |
F13 | REAR WNDW DEFOG |
F21 | E-BOOST PWR1 |
F23 | STRTR PINION |
F59 | N/A |
F62 | N/A |
F63 | N/A |
M-case Fuses | |
F04 | FRT WPR |
F30 | STRTR SOL |
F37 | AUX OIL PUMP |
F39 | N/A |
F43 | PWR WNDW RT |
F55 | PWR WNDW LT |
F60 | N/A |
F61 | N/A |
Mini Relays | |
K03 | RUN/CRNK |
K04 | REAR DEFOG |
K06 | STRTR PINION |
K08 | PT RLY |
K09 | N/A |
HC Micro Relays | |
K01 | N/A |
K02 | N/A |
K05 | STRTR SOL |
K07 | A/C CNTRL |
K10 | N/A |
Ultra Micro Relays | |
K11 | N/A |
Instrument Panel Fuse Block
List of fuses in the Instrument Panel Fuse Block (2024-2025)
№ | Usage |
---|---|
Fuse | |
F01 | LUMBAR |
F02 | SUNROOF |
F03 | VBAT_3 |
F04 | VBAT_7 |
F05 | VBAT_6 |
F06 | AUTO HVAC |
F07 | CGM |
F08 | ST WHL HTR |
F09 | DISPLAY |
F10 | RADIO |
F11 | ONSTAR (ERA) |
F12 | PARK ASSIST |
F13 | MAN. HVAC |
F14 | WL CHARGER |
F15 | VBAT_2 |
F16 | VBAT_1 |
F17 | SWC BKLT |
F18 | N/A |
F19 | N/A |
F20 | CLOCK SPRING |
F21 | OCC SEN |
F22 | DLC |
F23 | SDM |
F24 | IGN SW/ESCL |
F25 | PWR L-GATE MDL |
F26 | SEC FUSE-2 |
F27 | PWR SEAT CO-DR |
F28 | VBAT_8 |
F29 | DC-DC AT |
F30 | PWR L-GATE MDL |
F30 | OSRVM |
F32 | FRT HS PWR-1 |
F33 | VBAT_4 |
F34 | FRT HS PWR-2 |
F35 | AMPLIFIER |
F36 | ONSTAR (TCP) |
F37 | PWR SEAT DR |
F38 | DC-DC 400W |
F39 | SEC FUSE-1 |
F40 | HVAC_BLOWER |
Circuit Breaker | |
CB1 | N/A |
CB2 | APO |
Relay | |
K01 | i-RAP_ACC |
K02 | RUN |
K03 | LOGISTICS |
K04 | N/A |
K05 | N/A |
K06 | N/A |
Rear Compartment Fuse Block
List of fuses in the Rear Compartment Fuse Block (2024-2025)
№ | Usage |
---|---|
Fuse | |
F01 | N/A |
F02 | RDCM ELEC |
F03 | N/A |
F04 | N/A |
F05 | DC/AC INVERTER |
F06 | N/A |
F07 | RDCM |
F08 | RR SEAT HEAT PWR1 |
F09 | N/A |
F10 | RR SEAT HEAT PWR2 |
F11 | N/A |
F12 | N/A |
F13 | N/A |
F14 | N/A |
F15 | N/A |
F16 | N/A |
F17 | N/A |
F18 | N/A |
F19 | N/A |
F20 | N/A |
F21 | N/A |
Circuit Breakers | |
CB1 | N/A |
Relays | |
K01 | N/A |
K02 | N/A |
K03 | N/A |
K04 | N/A |
K05 | N/A |
Conclusion
The 2024-2025 Buick Encore GX combines style with technology, supported by a well-designed electrical system. Proper maintenance of the fuse box and relays is essential for optimal functionality.
