Learn about GMC Jimmy 1995-1997 fuse box and relay’s locations, functions, and maintenance tips for optimal vehicle electrical system.
The GMC Jimmy, from the years 1995-1997, boasts a signature compact SUV body style, featuring a classic design that has an undeniable appeal among enthusiasts. Its body style typically includes a two-door panel option and four-door panel. Customers have a variety of roof options, such as a hatchback or cargo, making it a versatile vehicle for all lifestyles. Three main trim levels tailor the customization and features of the GMC Jimmy, offering buyers individual choices like the base model, SLE, and SLT. As for its engine, customers can choose from several options, making it a surrounding or off-road vehicle according to personal preferences. You can select from a V6 4.3-liter or an I4 2.4-liter. The complete package includes a four-speed or six-speed automatic transmission system, making for a smooth and comfortable ride.
When it comes to the GMC Jimmy’s fuse box and relay, it functions through an intricate and well-designed electrical system. The fuse box predominantly aids in critical safety equipment and fuel management by regulating the vehicle’s power safely. Its location typically resides beneath the dashboard, intercepting the essential flow of electrical circuits to various components such as the ignition, fuel pump, and electrical accessories.
The relay coordinates its actions with other integrated components, such as the signal and headlight indicators, ventilation system, power opening mechanism, sunroof, and windows. The GMC Jimmy’s relay system serves as a guide for current distribution, ensuring that power reaches specific components without causing system overload.
MUST READ: DYI – How to Check Car Fuses?
(1995-1997) GMC Jimmy fuse box and relay with Diagram
WARNING
- Never replace a fuse with one that has a higher amperage rating.
- A fuse with a too-high amperage could damage the electrical part and cause a fire.
- On no account should fuses be repaired (e.g. patched up with tin foil or wire) as this may cause serious damage elsewhere in the electrical circuit or cause a fire.
- If a fuse blows repeatedly, do not keep replacing it. Instead, have the cause for the repeated short circuit or overload tracked and fixed.
- Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.
GMC Jimmy 1995-1997 fuse assignment
GMC Jimmy Year of production: 1995, 1996, 1997
Location of the Fuse Box
The fuse block is at the driver’s end of the instrument panel.
To Access: Remove the cover by turning the fastener counterclockwise.
Fuse Box Diagrams
1997
Instrument Panel Fuse Block
List of fuses in the Instrument Panel Fuse Block (1997)
| № | Usage |
|---|---|
| A | Power Door Locks, Power Seat, Power Seat Lumbar, Remote Keyless Entry |
| B | Power Windows, Sunfool Module / Motor |
| 1 | Stoplamps, Hazard Lamps, Chime, Center High-Mounted Stoplamp Relay, Center High-Mounted Stoplamp |
| 2 | Dome Lamps, Cargo Lamps, Visor Vanity Mirror, Cigarette Lighter, Inside Rearview Mirror Lamp, Overhead Console L,amps, Glove Box Lamp, Horns, Horn Relay, IP Courtesy Lamps, Power Outside Rearview Mirror, Liftglass Release Motor, Illuminated Entry Module |
| 3 | Parking Lamps, License Plate Lamps, Electric Shift Transfer Case Module, Underhood Lamp, Rear Wiper, Fog Lamp Relay, Door Switch Lamp, Ashtray Lamp, Headlamp Switch |
| 4 | A/C Compressor Relay, Cluster Chime Module, DRL Relay Coil, Four-Wheel-Drive Indicator Lamp, DRL Module, Rear Defog Timer, Transfer Case Control Module Ignition, SIR Redundant Ignition, RKE Ignition, Fuel Sender Module |
| 5 | Oxygen Sensor Heater, Exhaust Gas Recirculation, Cam Sensor, CANN, Purge, Canister Vent Solenoid, Mass Airflow Sensor, Cam Shaft Sensor |
| 6 | Blower Motor, Temperature Door Motor, HI Blower Relay Coil |
| 7 | Power Auxiliary Outlets, Assembly Line Diagnostic Link |
| 8 | Rear Window Defogger |
| 9 | PCM / VCM Battery, Fuel Pump |
| 10 | PCM / VCM Ignition, Injectors, Crank Sensor, Coil Driver Module |
| 11 | Radio, Inside Rearview Mirror Map Lamp, Overhead Console Reading Lamps, Rear Wiper, Rear Washer, Overhead Console Display |
| 12 | Anti-Lock Braking System, VCM IGN – 3 |
| 13 | Clock, Radio Battery, CD Player |
| 14 | A/C Compressor Battery Feed |
| 15 | Daytime Running Lamps, Fog Lamps, Fog Lamp Relay |
| 16 | Turn Signals and Back-up Lamps, Brake -Transmission Shift Interlock Solenoid |
| 17 | Windshield Washer, Windshield Wiper Motor |
| 18 | Not Used |
| 19 | Electric Shift Transfer Case |
| 20 | Crank Relay, Air Bag Module |
| 21 | Not Used |
| 22 | Air Bag Module |
| 23 | Cluster Illumination, Radio Illumination, Heater Lamp, 4WD Illumination, Chime Module, Fog Lamp Illumination, Rear Wiper Switch Illumination, Rear Defogger Switch Illumination, Iiftglass Release Switch Illumination, Overhead Console Illumination |
| 24 | PRNDL Power, 4L60E Automatic Transmission |
